CY-2
Wireless Data Link
UAV · UGV · Robotic Platforms
Video, telemetry, serial data, and IP tunnel over one compact vehicle-to-ground radio link.
5 GHz2×2 MIMO800 mW867 Mbps PHY
01
Features & ApplicationsRebhu Radio CY-2
Key Features
- 800 mW RF output
- 5 GHz digital wireless data link
- 2×2 MIMO / 2T2R radio architecture
- Compressed video, telemetry, UART, and IP traffic over a single link
- Ethernet, USB, UART, power, and dual-antenna interfaces
- Transparent IP tunnel / Ethernet bridge-style operation
- UART telemetry and IP telemetry workflows
- Configurable UART baud rate and serial settings
- Vehicle-side and ground-side deployment
- IP camera and USB camera workflows
- Local web monitoring for link and system visibility
- Suitable for cameras, autopilots, payload controllers, and onboard computers
Applications
| Application | Typical Use |
|---|---|
| UAV platforms | Camera video, telemetry, payload data, and onboard access |
| UGV / rover systems | Camera feed, robot telemetry, diagnostics, and service access |
| Mobile robots | Remote monitoring, IP access, payload data, and field integration |
| Embedded payloads | UART, Ethernet, and USB device connectivity |
| IP camera systems | Video transport from vehicle-side camera to operator-side system |
| Autopilot telemetry | UART telemetry and IP telemetry workflows |
| Field testing | Link monitoring, integration checks, diagnostics, and configuration |
| Onboard computer access | Web dashboard, SSH, API, and service access over the radio link |
02
SpecificationsRebhu Radio CY-2
Technical Specifications
| Radio band | 5 GHz, 5.15–5.85 GHz |
| Wireless technology | 802.11a/n/ac based digital wireless link |
| MIMO configuration | 2×2 MIMO / 2T2R |
| Channel bandwidth | 10 / 20 / 40 / 80 MHz |
| Peak PHY rate | Up to 867 Mbps |
| Practical data use | Compressed video + telemetry + UART + IP traffic over a single link |
| Power input | 5 V DC nominal |
| Radio current | Up to 1.8 A |
| Radio power draw | Up to approx. 9 W for radio section |
| Antenna ports | 2 × SMA external antenna connectors |
| Antenna mode | Dual-antenna 2×2 operation |
| Operating temperature | −20°C to +70°C |
| Operating humidity | 10–95% RH, non-condensing |
| Interfaces | Ethernet, USB, UART, power, dual antenna |
| Video support | IP camera, USB camera workflow, RTSP/UDP/TCP video transport |
| Telemetry support | UART telemetry and IP telemetry workflows |
| IP tunnel | Transparent IP tunnel / Ethernet bridge-style operation |
| UART configuration | Configurable baud rate and serial settings |
| Default topology | Point-to-point air-ground or vehicle-ground link |
03
ContactRebhu Radio CY-2
Discuss CY-2 for your platform
Share your platform type, interface requirement, video source, telemetry requirement, payload workflow, and deployment environment.
